Technical Specifications
| Standard |
IEC60034 |
| Frame size |
355X-450X |
| Output |
220kW-1000kW |
| Voltage / Frequency |
≤1000V / 50Hz, 60Hz |
| Protection degree |
IP55 / IP56 / IP65 / IP66 |
| Insulation / Temp Rise |
Class F / B |
| Mounting arrangements |
IM B3 / IM B35 / IM V1 |
| Ambient Temperature |
-15°C to +40°C |
| Relative Humidity: < 90% | Altitude: < 1000 meters |
| Cooling method |
IC416 |
| Duty |
S1 (Continuous) |
| Service factor |
1.0 |
Note: This information serves as a reference. Product specifications may be updated without prior notice. Please provide rated data (type, power, voltage, speed, insulation, protection, and mounting) when ordering.
Customization Options
➤
Special voltage, frequency, and power requirements.
➤
Enhanced insulation classes and protection ratings.
➤
Custom terminal box positioning (left side), double shaft ends, or special shaft designs.
➤
High-temperature or low-temperature specialized motors.
➤
Configurations for plateau or outdoor environmental conditions.
➤
High power output or specific service factor adjustments.
➤
Integration of heaters, PT100 for bearings/windings, and PTC thermistors.
➤
Encoders, insulated bearings, or specialized insulated bearing structures.
Frequently Asked Questions (FAQ)
What international standards do these motors comply with?
All motors are designed and manufactured according to the IEC60034 standard, ensuring global compatibility and reliability.
What is the available power range for this series?
This series covers a high-output range from 220kW up to 1000kW, suitable for heavy-duty industrial applications.
Can these motors be used in outdoor or high-altitude environments?
Yes, we provide specialized designs for outdoor use and plateau conditions where altitudes exceed the standard 1000-meter limit.
What protection ratings are available?
We offer multiple protection levels including IP55, IP56, IP65, and IP66 to protect against dust and water ingress depending on your environment.
What customization options are available for monitoring?
We can integrate various monitoring tools such as PT100 sensors for bearings or windings, PTC thermistors, and encoders for precision control.
What are the standard ambient operating conditions?
The standard operating temperature range is -15°C to +40°C, with relative humidity below 90% and altitude below 1000 meters.
